Product Details:
|
Model Name: | MG858S | Operating System: | Windows |
---|---|---|---|
Accuarcy: | Single-point: 1.2m | RTK: | Horizontal: 1cm+1ppm Vercial: 2cm+1ppm |
Memory: | RAM 258MB+ ROM 4G | Come With: | Wifi/ Bluetooth / WCDMA |
CPU: | MG8PLUS 833HZ | Positioning Time: | RTK Initializationa 120s |
Working Hours: | 14hours | Working Temperature: | -20℃- +60℃ |
Storage Temperature: | -30℃- +70℃ | Color: | Yellow |
Waterproof: | IP66 | ||
Highlight: | MG858S handheld gnss,handheld gnss receiver,handheld rtk gps |
Spectifications
Operating System | Windows mobile6.5 professional | ||||||
CPU: MG8PLUS 833MHz | |||||||
GNSS | Channels: 372 | ||||||
GPS:L1,BEIDOU: B1,GLONASS: L1 | |||||||
reserve upgrade for GALILEO,QZSS system | |||||||
Accuracy | Single-point: 1.2m | ||||||
SBAS: 0.3m | |||||||
DGPS: 0.2m | |||||||
RTK: horizontal: 1cm+1ppm;Vertical: 2cm+1ppm | |||||||
Positioning Time | Cold start:<60s,Low-temperature start:<30s,Warm start:<10s | ||||||
RTK initialization: 120s | |||||||
Memory | RAM: 258MB(Optional 512MB) | ||||||
ROM:4G(expand to 32G) | |||||||
Memory expansion:support SD card storage expansion | |||||||
Communication | Wireless communication: support WIFI,Bluetooth | ||||||
Network communication: standard 3.75G | |||||||
WCDMA network communication,sopport for voice calls | |||||||
USB: USB2.0 interface,support for USB OTG | |||||||
Screen | 3.7inch Blanview TFT transflective screen,resolution 640*480 pixels | ||||||
Power | 37.7W smart Li-ion battery,removable,with | ||||||
electricity indicator and temperature control chip | |||||||
Working time: typical 14 hours | |||||||
Environment | Working temperature: -20℃-+60℃ | ||||||
Storage temperature:-30℃-+70℃ | |||||||
Water/dustproof: IP66(Optional IP67) | |||||||
Shock:1.5meters drop to the hard ground without damage | |||||||
Humidity:95% non-condensing | |||||||
Extended Function | Camere: 5 mega pixels, support auto focus | ||||||
Support a microphone recording |
