LCD Display 5" DT405 Theodolite Survey Instrument

LCD Display 5" DT405 Theodolite Survey Instrument
LCD Display 5" DT405 Theodolite Survey Instrument LCD Display 5" DT405 Theodolite Survey Instrument

Large Image :  LCD Display 5" DT405 Theodolite Survey Instrument

Product Details:
Place of Origin: MADE IN CHINA
Certification: CE CERTIFICATE
Model Number: DT405/ DT405L
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: USD
Packaging Details: Package in carton
Delivery Time: 15 working days
Payment Terms: L/C, T/T
Supply Ability: 300pcs per year

LCD Display 5" DT405 Theodolite Survey Instrument

Accuracy: 5" Color: Green
Field Of View: 1°30′ Minimum Focus: 1.0m
Objective Aperture: φ45mm
High Light:

1.0m total station theodolite


DT405 optical theodolite


5" digital theodolite

DT405/DT405L 5" Accuracy Digital Theodolite for constrction


   DT405 DT405L
Image Erect
Objective aperture φ45mm
Magnification 30x
Field of view 1°30′
Minimum focus 1.0m
Angle measurement
Reading system absolute encoder
Minimum reading 1"/5"/10" (0.2mgon/1mgon/2mgon)
Accurancy 5"
Compensation range ±3”
Compensation setting accurancy 1
Display panel LCD on double sides
Reticle Yes
LCD display back light Yes
Level sensitivity
Plate level 30”/2mm
Circular level 8' /2mm
Power supply 6V Ni-mh rechargeable battery for 4pcs AA battery
Operation time 24 hrs with rechargeable battery
Laser plummet(standard)
Accuracy ±1.00mm/1.5m
Laser class Class 2 /IEC60825-1
Laser wave 635nm
Optical plummet (Factory optical)
Accuracy ±0.8mm/1.5m
Image Erect
Magnification 3x
Field of view
Focus range 0.5m to
Serial interface RS-232C
Dimension 53*30*30
Weight 10kg
Opertaion temperature -20℃~+50℃
Water and dust production IP55
