P9 GNSS RTK Receiver

Best Products
China GEO-ALLEN CO.,LTD. certification
China GEO-ALLEN CO.,LTD. certification
I'm Online Chat Now

P9 GNSS RTK Receiver

P9 GNSS RTK Receiver
P9 GNSS RTK Receiver P9 GNSS RTK Receiver

Large Image :  P9 GNSS RTK Receiver

Product Details:
Place of Origin: China
Brand Name: No Brand
Certification: No Certificate
Model Number: P9
Payment & Shipping Terms:
Minimum Order Quantity: 5PCS
Price: USD
Packaging Details: Package in box
Delivery Time: 15 Working Days
Payment Terms: T/T, L/C

P9 GNSS RTK Receiver

Operation System: Windows Mobile6.5 Screen Size: 3.7inch
Wifi: Wlan 802.11b/g Battery: 25.16w Big Capacity Battery
High Light:

3.7" handheld gnss


P9 GNSS Receiver


Handheld GNSS RTK Receiver

P9 Data Collector For GNSS Reciver




                                               P9 GNSS RTK Receiver 0

Model P9
Physical parameter
Operation system Windows Mobile6.5
Processor TI Sitara™ AM335x 1GHz
ROM 4Gboard flash memory(32Goption)
Screen 3.7inch Blanview TFT transflective screen,480×640VGAresolution ratio
Battery 25.16W big capacity battery,single battery endurance>10hours
Communication Bluetooth,Version2.1+EDR,USB OTG(directly conenct Uflash disk)

5millionpixel automati focusing

VGA resolution ratio video recording



3.5G WCDMA 900 / 2100MHz
WIFI WLAN 802.11b/g
Press button All digital alphabetmulti-functionkepboard,F1-F4definable shortcusts, lateral definable collect keys
Size Length192.0mm Width93.5mm thickness43.0mm
Weight 925g(with battery)
Protection level IP67
Temperature Opration temperature-20℃-+60℃,Storage temperature-30℃-+70℃
Humidity 5%-95%Rhnon-condensing
Drop 1.2meters fell on the cement plywood ground without damage




BeiDou 2rd generation B1

Channel 72
Positioning accuracy Horizontal 2 m CEP
Updating speed 1Hz (highest10Hz)
Data output NMEA-0183
Real-time correction RTCM 2.x,3.x



About us


Geo-Allen Co., Ltd. was founded in 2002, in Suzhou, Jiangsu Province, 80km away from Shanghai. Suzhou is a beautiful city, nicknamed “heaven on earth”, with more than 2500 years of history.

This May, Geo-Allen will celebrate its 17 years anniversary. In the past 17 years, Geo-Allen has grown to be a world famous company with an R&D team, a trading department, manufacturing workshops and an after-sales-service team. With the DNV’s ISO9001 certificate and 15 years of development, Geo-Allen is gaining more and more recognition in our field.

Geo-Allen's market almost covers the entire world, including West & East Europe, North & South America, Asia, Africa, and Oceania.

By strictly adhering to our policies of best service / best quality / best prices Geo-Allen has gained a high reputation from all of our customers.
Geo-Allen never stops expanding and developing. Its products now include UAVs, GNSS devices, total stations, theodolites, auto levels, laser instruments, and almost all kinds of accessories. Its R&D department is highly capable of designing and producing new products based on either customers' special inquiries or our own ideas in a very short period of time. We hold several approved patents for products that we’ve designed and we are in the process of applying for more.

With our goal of Punctuality, Quality, Rigor, and Service (P/Q/R/S), Geo-Allen has a vision of an even more beautiful future. Geo-Allen is looking forward to a bright new year in 2017 with all our friends around the world.
